Johansson 8701 - TITANIUM 8

The Johansson 8701 - TITANIUM 8 is a state-of-the-art compact headend transmodulator, engineered for efficient and reliable digital TV signal distribution. It is an excellent choice for a variety of applications, including hotels, hospitals, apartment buildings, and marine vessels. This unit is designed to transmodulate satellite signals to DVB-T or DVB-C, making it a perfect component for system upgrades from analog to digital.

Key Features:

• 8 DVB-S/S2 Tuners: Allows for the reception of 8 satellite transponders.
• 4 DVB-T/C Output MUXs: Provides 4 multiplexes for either digital terrestrial or cable distribution.
• 2 CI Slots: Includes two Common Interface slots for CAM cards to decode encrypted programs.
• Integrated Multiswitch: Offers flexible routing of satellite programs to the output multiplexes.
• User-Friendly Web Interface: Enables easy configuration and management through a built-in web server.
• Standalone Unit: Comes in a compact frame with its own built-in power supply.
• Advanced Functionality: Supports SID remapping, Local Channel Numbering (LCN), PID filtering, and EPG processing for forwarded services.

Technical Specifications:

• Input: QPSK/8PSK (DVB-S/-S2)
• Inputs: 4 satellite bands, 1 x RF in
• Frequency Range: 950 - 2150 MHz
• Input Level: 44 - 84 dBµV
• Output Level: 69 - 84 dBµV (adjustable)
• DVB-T Output: Up to 31.7 Mbps / MUX
• DVB-C Output: Up to 51.3 Mbps / MUX
• Power Consumption: 22 W (excluding external LNBs)
• Dimensions: 34.5 x 7 x 18.2 cm
